1010-1015nm Narrow linewidth laser
Based on high-power, low-noise thulium-doped fiber amplification and frequency-doubling technology, high-power and narrow-linewidth laser output with any central wavelength in the range of 1010-1015nm is achieved.
Features
- Narrow linewidth
- Low intensity noise
- High power
- Active power stabilization: <0.75% RMS, 3 hrs
- Excellent beam quality (M² <1.1)
- Mode-hop free
- Operable in high/low temperature and vibration environments
Application
- Optical lattice, atomic cooling and trapping
- Cold atomic physics / Quantum optics research
- Atomic clock
- Precision metrology
Main parameters
|
Specification |
|
|
Model Number |
FL-SF-XXXX-YY-CW(1) |
|
Optional Central Wavelength Range |
1010-1015nm |
|
Output Power |
＞0.02W |
|
Output Mode |
Single-mode PM fiber output |
|
Linewidth (2) (100μs integration time) |
＜15kHz |
|
Polarization Extinction Ratio |
Linear,＞20dB |
|
Power Stability |
＜0.75%@3hours, RMS |
|
Beam Quality |
TEM00，M2＜1.1 |
|
PZT Tuning Range |
＞3GHz |
|
PZT Tuning Bandwidth |
＞5kHz |
|
AOM Tuning Range |
＞±5MHz |
|
AOM Tuning Bandwidth |
＞500kHz |
|
Relative Intensity Noise |
＜0.08%（RMS,integrated over 10Hz-100MHz） |
|
Cooling |
Air Cooling |
(1)XXXX is the wavelength and YY is the output power, for 0.02W 1013nm laser, the partnumber is FL-SF-1013-0.02-CW.
(2)Measured by self-hetrodyne method
Higher power, more wavelengths, customizable solutions
